Double Adjustable Rear Shock Mopar - Multiple Applications (ea)

Applications

1970-1974 Challenger
1965-1972 Charger / Coronet
1962-1976 Dart / Demon
1964-1974 Barracuda
1962-1972 Belvedere / Satellite
1960-1976 Duster / Valiant / Scamp
1962-1964 Fury

Description

Double Adjustable Aluminum Shock
Rear – Sold as each

Drag Racing
Softening extension allows more downward force on the rear tires
Stiffening compression delays the return to normal ride height

Performance Street / Road Racing
Stiffening extension & compression reduces body roll
Enhances handling & cornering characteristics

Rotating Knobs Clockwise Stiffens Valving

Dimension A

Extended 22.24" / Compressed 14.2"

Features

• Lightweight aluminum body
• 10 extension & compression settings
• Provides a wide range of control
• Easily accessible independent external adjustment knobs
• Allows quick changes for varying conditions
• Custom valving available upon request
• Ability to be rebuilt or revalved

Includes

– Upper & lower polyurethane bushings
– Steel inner sleeves

Related Components

Front Shock
Single adjustable…………. S5281 / S5283
Double adjustable……….. S5081 /S5083
